Oldham Simtronics SG50-F-IR3-H2-V-AS13 Xtend Triple IR (IR3) SG50-F for Energy Transition Fires

What is the Oldham Simtronics SG50-F-IR3-H2-V-AS13?

The Oldham Simtronics SG50-F-IR3-H2-V-AS13 is: Xtend Triple IR (IR3) SG50-F for Energy Transition Fires – HC & Hydrogen, with Near IR HD camera, HART, SIL2, M25. This reference is the triple infrared (IR3) version of the Spyglass SG50-F flame detector, built for energy transition fires such as hydrogen, in a stainless steel 316 housing, with an on-board camera.

What are the specifications of the SG50-F-IR3-H2-V-AS13?

• Detection technology of this reference: triple infrared (IR3), for energy transition fires such as hydrogen
• Adjustable time delay 0 to 30 seconds
• Power supply 24 V DC nominal (18 to 32 V DC)
• Cable entries: two conduit entries, one plugged with a certified stopper; this reference uses M25
• HART communication, as listed in the part description
• Functional safety: certified SIL 2 per IEC 61508, as listed in the part description
• On-board camera, as listed in the part description

What should you check before ordering?

Order by the exact part number and check the options its part description lists (HART, SIL 2, NFPA 33 compliance, cable entry thread) against the site requirement: references that look alike can differ on approval scope rather than on the sensor.

Where is it used?

Typical service: Hydrogen and alternate energy fuel fires; Incident review with the on-board video.

How do I order or get a quote?

PE Energy supplies the Oldham Simtronics SG50-F-IR3-H2-V-AS13 on a quote basis: send the part number with your application details and we return pricing and lead time. Fixed gas and flame detection is quoted rather than listed because most references ship configured for target gas, range, approval scope and cable entry, and those choices are fixed at the part number.
