Hydrotex Ultra-Kleen™ XPL FRHF

Price range: $2,512.15 through $12,765.21

Grade

Pack size

Clear

SKU: N/A

Manufacturer:

Hydrotex

Bulk Orders

Competitive Pricing

Short Lead Times

Consolidated Shipping

Prompt Response

Request a Quote

What is Hydrotex Ultra-Kleen™ XPL FRHF?

Ultra-Kleen™ XPL FRHF is a food grade hydraulic fluid designed to replace mineral oil-based anti-wear hydraulic fluids in applications with fire hazards or environmental concern. Formulated with renewable biosynthetic esters and non-toxic additives, Ultra-Kleen XPL FRHF provides maximum wear protection for extended asset life and the ultra-high viscosity index delivers improved hydraulic efficiency and productivity. The readily biodegradable fluid has low aquatic toxicity and will not bioaccumulate, minimizing the environmental damage and cleanup expense for an accidental release.

Why choose Hydrotex Ultra-Kleen™ XPL FRHF?

Lowers fire risks and impacts
Excellent wear resistance
Ultra-high viscosity index for efficiency over a wide temperature range
Superior air release & demulsibility
Compatible with traditional mineral oil hydraulic fluids & elastomers
Oil Lubricated Hydraulic Systems
Food Processing Equipment
Paper & Corrugated Equipment

Which specifications does Hydrotex Ultra-Kleen™ XPL FRHF meet?

ASTM D8029
DIN 51502 HFDU
EPA Vessel General Permit
FM Approval Standard 6930
ISO 12922 HFDU
ISO 15380 HEES
ISO 6743-4 HFDU
ISO Grade
NSF H1

Hydrotex has not supplied an NSF registration for this product. Ask us for it before specifying it for incidental food contact.

Hydrotex Ultra-Kleen™ XPL FRHF technical specifications

Property	Test method	ISO 46
ISO Grade	ASTM D2422	46
Kinematic Viscosity, cSt @ 40°C	ASTM D445	46.5
Kinematic Viscosity, cSt @ 100°C	ASTM D445	9.4
Viscosity Index	ASTM D2270	192
Flash Point, °F (°C)	ASTM D92	> 572 (300)
Pour Point, °F (°C)	ASTM D97	-49 (-45)
Density, g/ml @ 15.5°C	ASTM D1298	0.919
Density, lb/gal @ 60°F	ASTM D1298	7.67
4-Ball Wear, scar diameter, mm	ASTM D2266	0.49
FZG Scuffing, A/8.3/90, Fail Stage	ASTM D5182	12+
Copper Corrosion, 3 hr @ 121°C	ASTM D130	1B
Rust Test, Distilled Water	ASTM D665A	Pass
Rust Test, Syn. Sea Water	ASTM D665B	Pass
– Shore A Hardness Change, %	—	-5.9
– Volume Change, %	—	6.5
Air Release, min @ 50°C	ASTM D3427	2.5
Appearance, @ 25°C	—	Clear & Bright
Biodegradability, %	OECD 301B	> 60
Dynamic Viscosity, cP @ -10°C	ASTM D7042	550
Dynamic Viscosity, cP @ -20°C	ASTM D7042	1300
Dynamic Viscosity, cP @ -30°C	ASTM D7042	3750
Dynamic Viscosity, cP @ 0°C	ASTM D7042	300
Fire Point, °F (°C)	ASTM D92	> 680 (360)
Foam, Blow/Settle ml/ml, Seq. I, II, III	ASTM D892	pass
KRL Shear Stability, % visc. loss after 20hr	CEC L-45-A-99	<1
Nitrile Elastomer Compatibility	ASTM D471	SRE-NBR 1 @ 100°C for 168hr
Renewable Content, %	ASTM D6866	> 90
TOST Oxidation Stability, hrs	ASTM D943	2000+
V104C Pump Wear, wt. loss vanes, mg	ASTM D7043	< 5
Viton Elastomer Compatibility	ASTM D471	FKM 2 @ 95°C for 1008hr
Water Separability, min @ 54°C	ASTM D1401	15

Which pack sizes are available?

Part number	Grade	Pack size	Unit
5750-046-1	ISO 46	1900 LB	Tote
5750-046-2	ISO 46	400 LB	Drum

Is Hydrotex Ultra-Kleen™ XPL FRHF hazardous to handle?

Not classified as hazardous under GHS criteria. Land transport (DOT): Not Regulated for Land Transport. Consult the safety data sheet before use.

How do I order Hydrotex Ultra-Kleen™ XPL FRHF?

The list price for each pack is shown on this page and every pack is ordered by quote. Ordered by quote: 400 LB and 1900 LB – shipping for these packs is quoted per order, so send us the part number from the pack table above and we will confirm the delivered price. A grade or pack that is not listed is quoted the same way.
