CSB-1006 Replacement Battery Pack, Replaces RBC11, 4 x GP12170 12V 17Ah

What is the CSB-1006?

The CSB-1006 is a CSB replacement battery pack that replaces RBC11. It contains 4 CSB GP12170 12 V 17 Ah sealed lead-acid batteries with 100 A fuse and harness kit, as listed on the CSB price list.

CSB packs each replacement pack individually in a ready-to-ship carton and manufactures packs to order.

What are the specifications of the CSB-1006?

Replaces: RBC11
Batteries in the pack: 4 x CSB GP12170
Battery voltage and capacity (CSB price list): 12 V, 17 Ah each
Included: 100 A fuse and harness kit

What battery is inside the CSB-1006?

Figures for one CSB GP12170 battery, from the CSB GP12170 datasheet (2026 edition):

Weight per battery, approx.: 12.12 lb (5.5 kg)
Battery dimensions (L x W x H): 181 x 76.2 x 167 mm (7.13 x 3 x 6.57 in)
Battery terminal: B1/B1B/B3 terminal for M5 bolt
Battery design life: up to 5 years in standby service at 25 °C; Eurobat (20 °C) classification: 3-5 years, standard commercial

How do I request a quote for the CSB-1006?

Request a quote by the part number CSB-1006. Tell us the quantity you need and we confirm price, availability and lead time with the quote.
