CSB GP1272F2FR 12V 7.2Ah Sealed Lead-Acid Battery, Flame-Retardant Case

What is the CSB GP1272F2FR?

The CSB GP1272F2FR is a 12 V, 7.2 Ah valve-regulated lead-acid (VRLA) battery with absorbent glass mat (AGM) construction from the CSB GP series (General Purpose). It is sealed and maintenance-free: it never needs water.

CSB designs this series for float service standby power. This part number has a flame-retardant (UL 94-V0) case as standard.

What are the specifications of the CSB GP1272F2FR?

Figures published by CSB in the GP1272 datasheet (2026 edition), with the CSB price list attributes marked:

Nominal voltage: 12 V
Nominal capacity (CSB price list): 7.2 Ah
Rated capacity, 20-hour rate to 1.75 V/cell, 25 °C: 8.24 Ah
Rated capacity, 8-hour rate to 1.75 V/cell, 25 °C: 7.46 Ah
Maximum charge current: 2.16 A
Maximum discharge current: 130 A
Internal resistance: approx. 23 mΩ
Terminal: F2, Faston tab 0.250 in
Container: flame-retardant ABS, UL 94-V0 (this part number)
Flame-retardant case: standard on this part number (CSB price list)
Weight, approx.: 5.29 lb (2.4 kg)
Dimensions (L x W x H): 150.9 x 64.8 x 98.6 mm (5.94 x 2.55 x 3.88 in)
Case / group size (CSB price list): M7
Design life: up to 5 years in standby service at 25 °C; Eurobat (20 °C) classification: 3-5 years, standard commercial
Discharge temperature range: -15 to 50 °C
Float charging voltage: 13.5 – 13.8 V per battery at 25 °C (77 °F)
Equalize / cycle charging voltage: 14.4 – 15.0 V per battery at 25 °C (77 °F)
Standards (CSB datasheet): IEC 61056-1/2:2012, UL1973 Listed (MH66728) and UL1989 Recognized (MH14533)

How much power does the CSB GP1272F2FR deliver in a 15-minute discharge?

CSB’s constant-current table gives 15.3 A for 15 minutes to 1.67 V/cell at 25 °C, and the constant-power table gives 172 W per battery to the same end voltage. These are the figures to size a UPS or standby string against a 15-minute runtime.

How do I request a quote for the CSB GP1272F2FR?

Request a quote by the part number GP1272F2FR. Tell us the quantity you need and, where CSB lists more than one terminal or case option, which one. We confirm price, availability and lead time with the quote.
