Hydrotex SYN-Nth HyTrax™ Transmission and Hydraulic Drive Fluid

Price range: $397.03 through $13,320.26

Grade

Pack size

Clear

SKU: N/A

Manufacturer:

Hydrotex

Bulk Orders

Competitive Pricing

Short Lead Times

Consolidated Shipping

Prompt Response

Request a Quote

What is Hydrotex SYN-Nth HyTrax™ Transmission and Hydraulic Drive Fluid?

POWER KLEEN™ SYN-NTH HYTRAX DOES MORE WITH LESS Fuel Consumption (kg/hr) Work Cycles per Hour 90% Throttle Full Throttle 90% Throttle Full Throttle CAT HYDO Advance 10 15.2 19.5 40.0 53.5 SYN-Nth HyTrax 13.9 16.8 49.7 56.6 % Improvement 8.6% 13.8% 24.3% 5.8% In a controlled field trial comparing performance versus CAT HYDO Advanced 10 in a 318C model excavator, SYN-Nth showed major improvements in fuel efficiency and hydraulic system response, as evidenced by the number of work cycles completed per hour. Oil analysis results also indicated a safe drain interval extension of over 60%.

Why choose Hydrotex SYN-Nth HyTrax™ Transmission and Hydraulic Drive Fluid?

Improves hydraulic efficiency and system response
Prevents clutch slippage and chatter
Extreme pressure and anti-wear protection
Excellent oxidation stability for extended drains
Superior foam control and demulsibility
Protects over a wise temperature range

Where is Hydrotex SYN-Nth HyTrax™ Transmission and Hydraulic Drive Fluid used?

Powershift Transmissions
Final Drives
Oiled Bearings
Manual Transmissions
Speed Reducers
Allison Transmissions
Industrial Gears
Toro, Exmark and Husqvarna hydrostatic transmissions

Which specifications does Hydrotex SYN-Nth HyTrax™ Transmission and Hydraulic Drive Fluid meet?

Allison C-4
Komatsu KES 07.868.1
SAE 10W and SAE 30 grades
SAE30
ZF TE-ML 03C
ZF TE-ML 07F

Hydrotex SYN-Nth HyTrax™ Transmission and Hydraulic Drive Fluid technical specifications

Property	Test method	SAE 10W-40
SAE Grade	SAE J300	10W-40
Kinematic Viscosity, cSt @ 40°C	ASTM D445	92.7
Kinematic Viscosity, cSt @ 100°C	ASTM D445	14.7
Viscosity Index No.	ASTM D2270	165
Flash Point, °F (°C)	ASTM D92	428 (220)
Pour Point, °F (°C)	ASTM D97	-40 (-40)
Density, LB/gal @ 60°F	ASTM D1298	7.24
Density, kg/l @ 15.5°C	ASTM D1298	0.868
Color	—	Blue
4-Ball EP, Weld Point, kgf	ASTM D2596	200
4-Ball Wear, scar diameter, mm	ASTM D4172	0.53
FZG Scuffing Wear Test, Failure Load Stage	ASTM D5182	12+
Rust Test, Distilled Water	ASTM D665A	Pass
Rust Test, Syn. Sea Water	ASTM D665B	Pass
Allision THOT Oxidation Test	—	Pass
Copper Strip Corrosion, 100°C, 3 hr	ASTM D130	1A
Water Demulsibility	ASTM D1401	Pass

Which pack sizes are available?

Part number	Grade	Pack size	Unit
4101-X-1	SAE 10W-40	275 Gal	Tote
4101-X-2	SAE 10W-40	55 Gal	Drum
4101-X-5	SAE 10W-40	16 Gal	Drum
4101-X-6	SAE 10W-40	6/1 Gal	Case

Is Hydrotex SYN-Nth HyTrax™ Transmission and Hydraulic Drive Fluid hazardous to handle?

No safety data sheet has been supplied for SAE 10W-40, so no hazard classification or transport status is stated here – ask us for the sheet before ordering that grade.

How do I order Hydrotex SYN-Nth HyTrax™ Transmission and Hydraulic Drive Fluid?

The list price for each pack is shown on this page. Ordered by quote: 55 Gal and 275 Gal – shipping for these packs is quoted per order, so send us the part number from the pack table above and we will confirm the delivered price. Add to cart: 6/1 Gal and 16 Gal – pick the grade and pack size and check out directly. A grade or pack that is not listed is quoted the same way.
