Hydrotex® SYN-Nth™ Gear Oils
Price range: $370.34 through $22,855.38
Saving for lubricating gearboxes by reducing peak electric demand on start-up and wattage consumption during continuous operations. SYN- Nth Gear Oils are based on advanced synthetic hydrocarbon technology that minimizes viscosity changes at temperature extremes. Superior Wear Protection will protect your gears and bea
Bulk Orders
What is Hydrotex® SYN-Nth™ Gear Oils?
Saving for lubricating gearboxes by reducing peak electric demand on start-up and wattage consumption during continuous operations. SYN- Nth Gear Oils are based on advanced synthetic hydrocarbon technology that minimizes viscosity changes at temperature extremes. Superior Wear Protection will protect your gears and bearings even under extreme loads. Outstanding Oxidation Stability allows significantly longer oil
Why choose Hydrotex® SYN-Nth™ Gear Oils?
- Optimal protection from scuffing and micro-pitting wear for highly loaded and high slide-to-roll ratio gear systems
- Outstanding oxidation stability to maximize oil drain intervals and reduce oil consumption
- Ultra-high viscosity index ensures ideal film thickness across a wide range of temperatures
- Advanced viscometrics and low friction reduce energy consumption and operating temperatures
- Excellent low temperature performance and fluidity
- Extremely shear stable
- AGMA 9003-F16 AS
- JIS 2219 CLASS 2
Where is Hydrotex® SYN-Nth™ Gear Oils used?
- Wind Turbines
- Industrial Gears
- Planetary Gear Sets
- Speed Reducers
- Precision Gears
- Transmissions
- Spur Gears
- Helical Gears
- Herringbone Gears
- Spiral Bevel Gears
- Worm Gears
Which specifications does Hydrotex® SYN-Nth™ Gear Oils meet?
- AGMA 9003-F16 AS
- AGMA 9005-F16 AS
- API GL-4
- DIN 51517-3 CLP
- Fives Cincinnati P-77/74/59/35/34
- ISO 12925-1 CKT
- ISO 220
- JIS K 2219 Class 2
Hydrotex® SYN-Nth™ Gear Oils technical specifications
| Property | Test method | ISO 150 | ISO 220 | ISO 320 | ISO 390 | ISO 460 | ISO 680 |
|---|---|---|---|---|---|---|---|
| ISO Grade | ASTM D2422 | 150 | 220 | 320 | — | 460 | — |
| SAE Grade | SAE J306 | 80W-110 | 80W-140 | 80W-190 | — | 250 | — |
| AGMA No. | — | 4 | 5 | 6 | — | 7 | — |
| Kinematic Viscosity, cSt @ 40°C | ASTM D445 | 150 | 220 | 320 | 390 | 460 | — |
| Kinematic Viscosity, cSt @ 100°C | ASTM D445 | 21.4 | 29.0 | 37.7 | 43.6 | 49.2 | — |
| Viscosity Index No. | ASTM D2270 | 167 | 170 | 167 | 167 | 167 | — |
| Flash Point, °F (°C) | ASTM D92 | 410 (208) | 425 (219) | 430 (221) | 440 (227) | 450 (232) | — |
| Pour Point, °F (°C) | ASTM D97 | -38 (-39) | -33 (-36) | -27 (-33) | -27 (-33) | Confirmation pending | — |
| Density, g/mL @ 15.6°C | ASTM D1298 | 0.8813 | 0.8874 | 0.8953 | 0.8992 | 0.9027 | — |
| Density, lb/gal @ 60°F | ASTM D1298 | 7.355 | 7.406 | 7.471 | 7.504 | 7.533 | — |
| Color | — | Light Amber | Light Amber | Light Amber | Light Amber | Light Amber | — |
| 4-Ball EP, Weld Point, kgf | ASTM D2596 | 250 | 250 | 250 | 250 | 315 | — |
| 4-Ball Wear, scar diameter, mm | ASTM D2266 | 0.35 | 0.36 | 0.33 | 0.33 | 0.36 | — |
| Copper Corrosion, 3 hr @ 100ºC | ASTM D130 | 1a | 1a | 1a | 1a | 1a | — |
| Rust Test, Distilled Water | ASTM D665A | Pass | Pass | Pass | Pass | Pass | — |
| Rust Test, Syn. Sea Water | ASTM D665B | Pass | Pass | Pass | Pass | Pass | — |
| Foaming Test, Seq. I, II, and III | ASTM D892 | Pass | Pass | Pass | Pass | Pass | — |
| Fail Stage, FZG A/16.6/90 | Modified ASTM D5182 | 14+ | 14+ | 14+ | 14+ | 14+ | — |
| Fail Stage, FZG A10/16.6R/90 | — | — | — | 12 | 12 | — | — |
| Pressure DSC Oxidation Induction Time, min @ 185°C | ASTM D5483 | 82.5 | 82.5 | 82.5 | 82.5 | 82.5 | — |
| Roller wear, mg | DIN 51819-3 | — | — | < 2 | — | — | — |
Which pack sizes are available?
| Part number | Grade | Pack size | Unit |
|---|---|---|---|
| 0950-150-1 | ISO 150 | 275 Gal | Tote |
| 0950-150-2 | ISO 150 | 55 Gal | Drum |
| 0950-150-6 | ISO 150 | 6/1 Gal | Case |
| 0950-150-8 | ISO 150 | 5 Gal | Pail |
| 0950-220-2 | ISO 220 | 55 Gal | Drum |
| 0950-220-6 | ISO 220 | 6/1 Gal | Case |
| 0950-220-8 | ISO 220 | 5 Gal | Pail |
| 0950-320-1 | ISO 320 | 275 Gal | Tote |
| 0950-320-1B | ISO 320 | 330 Gal EZ-Bulk | Tote |
| 0950-320-2 | ISO 320 | 55 Gal | Drum |
| 0950-320-6 | ISO 320 | 6/1 Gal | Case |
| 0950-320-8 | ISO 320 | 5 Gal | Pail |
| 0950-390-1 | ISO 390 | 275 Gal | Tote |
| 0950-390-2 | ISO 390 | 55 Gal | Drum |
| 0950-390-8 | ISO 390 | 5 Gal | Pail |
| 0950-460-1 | ISO 460 | 275 Gal | Tote |
| 0950-460-2 | ISO 460 | 55 Gal | Drum |
| 0950-460-6 | ISO 460 | 6/1 Gal | Case |
| 0950-460-8 | ISO 460 | 5 Gal | Pail |
| 0950-680-2 | ISO 680 | 55 Gal | Drum |
| 0950-680-8 | ISO 680 | 5 Gal | Pail |
Is Hydrotex® SYN-Nth™ Gear Oils hazardous to handle?
signal word WARNING; Skin sensitization – Category 1. Land transport (DOT): Not Regulated for Land Transport. Consult the safety data sheet before use.
How do I order Hydrotex® SYN-Nth™ Gear Oils?
The list price for each pack is shown on this page. Ordered by quote: 55 Gal, 275 Gal and 330 Gal EZ-Bulk – shipping for these packs is quoted per order, so send us the part number from the pack table above and we will confirm the delivered price. Add to cart: 6/1 Gal and 5 Gal – pick the grade and pack size and check out directly. A grade or pack that is not listed is quoted the same way.
0950-100 SDS
0950-150 SDS
0950-220 SDS
0950-320 SDS
0950-390 SDS
0950-460 SDS
0950-680 SDS
TDS
Additional information
| Weight | N/A |
|---|---|
| Grade | ISO 150, ISO 220, ISO 320, ISO 390, ISO 460, ISO 680 |
| Pack size | 275 Gal Tote, 330 Gal EZ-Bulk Tote, 5 Gal Pail, 55 Gal Drum, 6/1 Gal Case |
