Hydrotex PIN-TAC™ Mining & Construction Grease

Price range: $94.54 through $3,849.71

Grade

Pack size

Clear

SKU: N/A

Manufacturer:

Hydrotex

Bulk Orders

Competitive Pricing

Short Lead Times

Consolidated Shipping

Prompt Response

Request a Quote

What is Hydrotex PIN-TAC™ Mining & Construction Grease?

PIN-TAC™ Mining & Construction Grease is formulated with Hydrosynthetic® base stocks and the latest extreme pressure additive technology fortified with a high concentration of molybdenum disulfide solid lubricants. PIN-TAC is specially formulated to provide maximum, long-lasting protection to pins and bushings against corrosion, water washout and the pounding of heavy loads at the extreme pressures and temperatures generated by heavy-duty mining and construction equipment.

Why choose Hydrotex PIN-TAC™ Mining & Construction Grease?

Maximum extreme pressure and anti-wear protection
Tacky formulation resists sling-off and pound out
Excellent resistance to water washout and corrosion
High temperature performance and low temperature fluidity
Superior fretting wear protection for static loads
Contains 3% technical fine Moly EP additive
Highly pumpable; ideal for use in automatic lubrication systems
Available in NLGI Grades #1 and #2

Where is Hydrotex PIN-TAC™ Mining & Construction Grease used?

Mining Equipment
Construction Equipment
Bucket Pins
Pins & Bushings
Bearings
Sliding Surfaces
Chassis Points
Fifth Wheels
Couplings
Draglines
Walking Cams
Wellhead Grease

Which specifications does Hydrotex PIN-TAC™ Mining & Construction Grease meet?

ASTM 1742
NLGI Grades

Hydrotex PIN-TAC™ Mining & Construction Grease technical specifications

Property	Test method	NLGI 1	NLGI 2
NLGI Grade	ASTM D217	1	2
Thickener Type	—	Lithium 12-hydroxystearate	Lithium 12-hydroxystearate
Base Oil Viscosity, cSt @ 40°C	ASTM D445	229	305
Base Oil Viscosity, cSt @ 100°C	ASTM D445	23.5	29.8
Base Oil Viscosity Index	ASTM D2270	127	133
Dropping Point, °F (°C)	ASTM D2265	397 (203)	399 (204)
Worked Penetration, 1/10th mm	ASTM D217	320	275
Color	—	Dark Gray	Dark Gray
4-Ball EP, Weld Point, kgf	ASTM D2596	400	400
Copper Corrosion, 24hr @ 100°C	ASTM D4048	1b	1b
Rust Test, Distilled Water	ASTM D1743	Pass	Pass
Rust Test, Synthetic Sea Water	ASTM D5969	Pass	Pass
Water Wash-Out, % Loss @ 80°C	ASTM D1264	< 2.0	< 1.0
Lincoln Ventmeter Test, psi @ 0°F	—	—	1775
Lincoln Ventmeter Test, psi @ 30°F	—	—	650
Lincoln Ventmeter Test, psi @ 72°F	—	—	475
Mechanical Stability, % change from worked penetration after 100,000 strokes	ASTM D217	4	6
Tackiness Index, Work/Elongation	Hydrotex	16/30	16/30

Which pack sizes are available?

Part number	Grade	Pack size	Unit
0820-1-12	NLGI 1	18/14 oz	Case
0820-1-5	NLGI 1	120 Lbs	Drum
0820-1-8	NLGI 1	35 Lbs	Pail
0820-1-8B	NLGI 1	35 Lbs	Pail
0820-1-9	NLGI 1	36/14 oz	Case
0820-2-12	NLGI 2	18/14 oz	Case
0820-2-13	NLGI 2	9/14 oz	Case
0820-2-2	NLGI 2	400 Lbs	Drum
0820-2-5	NLGI 2	120 Lbs	Drum
0820-2-8	NLGI 2	35 Lbs	Pail
0820-2-9	NLGI 2	36/14 oz	Case

Is Hydrotex PIN-TAC™ Mining & Construction Grease hazardous to handle?

signal word WARNING; Eye irritation – Category 2. Land transport (DOT): Not Regulated for Land Transport. Consult the safety data sheet before use. No safety data sheet has been supplied for NLGI 1, so neither the classification nor the transport status above covers it – ask us for the sheet before ordering that grade.

How do I order Hydrotex PIN-TAC™ Mining & Construction Grease?

The list price for each pack is shown on this page. Ordered by quote: 400 Lbs – shipping for these packs is quoted per order, so send us the part number from the pack table above and we will confirm the delivered price. Add to cart: 9/14 oz, 18/14 oz, 36/14 oz, 35 Lbs and 120 Lbs – pick the grade and pack size and check out directly. A grade or pack that is not listed is quoted the same way.
