Deacon PUMP 99, PUMP 77 PTFE Based Injectable Pump Packing

What is the Deacon PUMP 99, PUMP 77 PTFE Based Injectable Pump Packing?

Non-curing, Putty-like compound, Designed for rotating shaft packing glands, Pump 99 (black) contains PTFE and lead shot. Pump 77 (white) contains PTFE and stainless steel fibers and is non-staining. Shelf-life is 2 years in closed containers.

What are the specifications of the PUMP 99, PUMP 77 PTFE Based Injectable Pump Packing?

• Service Rating Temperature: -50ºF to 450ºF (-45ºC to 232ºC) Pressure: 0 to 300 PSI Shaft Speed: Up to 4150 SFM pH range: 0 -14
• 5/8" x 3" Plugs, J-Sticks, 7/8" x 6" Sticks

What are the characteristics of the PUMP 99, PUMP 77 PTFE Based Injectable Pump Packing?

• Repack simply by adding additional material as needed (old packing does not need removed)
• Permanently pliable
• 100% consumable
• High chemical resistance

Where is the PUMP 99, PUMP 77 PTFE Based Injectable Pump Packing used?

• Rotary pumps, Valves, Centrifugal pumps, Agitators, Reciprocating pumps, Mixers, Turbine pumps, Refiners, Dryers

Which Deacon PUMP 99, PUMP 77 PTFE Based Injectable Pump Packing do I order?

• Pump 77 J-Stick: part number 111-PUMP-77 J-STICK
• Pump 99 J-Stick: part number 111-PUMP-99 J-STICK
• Pump 99 Plug (Pack of 100): part number 111-PUMP-99 PLUG

Some options here are sold by the pack and some as a single item, and the price follows the option: Pump 99 Plug (Pack of 100) is pack of 100. Every other option is one item.

How does this grade compare with the rest of the Deacon range?

Across the 55 Deacon injectable sealants and compounds PE Energy stocks, this one is rated Temperature: -50°F to 450°F (-45°C to 232°C) Pressure: 0 to 300 PSI Shaft Speed: Up to 4150 SFM pH range: 0 -14. That places it above 5 of the other 54 on upper service temperature: 427 Two-Part Epoxy – Resin Pours / Void Fill stops at 400°F, and 300 PTFE continues to 500°F.

Deacon publishes these ratings one product page at a time, so the comparison above is the part that is hard to assemble before you order. If your service condition sits near a boundary, send us the temperature and the medium with your enquiry and we will confirm the grade against the 2026 manufacturer catalogue before quoting.

How do I order or get a quote?

PE Energy supplies the Deacon PUMP 99, PUMP 77 PTFE Based Injectable Pump Packing from the 2026 manufacturer catalogue. Order the part number for the option you need, or send us the part number with your application details and we return pricing and lead time.
