Deacon 3300 Extruded Gasket Compound

What is the Deacon 3300 Extruded Gasket Compound?

Deacon 3300 is a fully compressible putty-like joint sealant that is packaged on a spool, in various diameters and lengths. Rated to 1600F (871C) and 1500 PSI (103 Bar), it can be used to replace a gasket or in conjunction with traditional fabricated gaskets to seal against steam, hot air, and various chemical environments. Deacon 3300 allows for a fast / easy repair and can be used to eliminate a costly inventory of various sized gaskets and types. Simply compressing the cord between two mating surfaces will achieve an initial seal. Upon heat exposure from startup, the product will cure to a flexible leather- like consistency that will not cement the joints together (remains removeable). Ideal for joint applications that have surface defects, steam cuts, pits, and other irregularities, Deacon 3300 can compress down to 0.002 inches (0.05 mm) to fill the voids and achieve a leak-free seal. Equipment types include access doors, boilers, turbines, heat exchangers, and incinerators. When trying to determine the thickness of Deacon 3300 required, a general rule for sufficient sealant compression is three times the thickness of the gap to be sealed. Example: 1/8” flange cut or gap = 3/8” Dia. Sealant

What are the specifications of the 3300 Extruded Gasket Compound?

• Base Materials Resin
• Service Rating 600°F (315°C) to 1600°F (871°C) Up to 1500 psi (103 Bar)

Which Deacon 3300 Extruded Gasket Compound do I order?

• 3300 1/2" 5 lb. Roll (37 ft.): part number 111-3300 1/2 INCH 5 LB
• 3300 1/4" 1 lb. Roll (34 ft.): part number 111-3300 1/4 INCH 1 LB
• 3300 3/4" 5 lb. Roll (19 ft.): part number 111-3300 3/4 INCH 5 LB
• 3300 3/8" 1 lb. Roll (17 ft.): part number 111-3300 3/8 INCH 1 LB
• 3300 3/8" 5 lb. Roll (80 ft.): part number 111-3300 3/8 INCH 5 LB
• 3300 1/4" x 17 in. Piece: part number 111-3300 1/4 INCH 17 IN

What should you check before ordering the 3300 Extruded Gasket Compound?

[PROOF: FIELD OBSERVATION, COST COMPARISON OR FAILURE MODE FOR THIS PRODUCT, WITH DATE AND CONDITIONS]

How do I order or get a quote?

PE Energy supplies the Deacon 3300 Extruded Gasket Compound from the 2026 manufacturer catalogue. Order the part number for the option you need, or send us the part number with your application details and we return pricing and lead time.
