Deacon 3100-S Injectable Sealant

What is Deacon 3100-S Injectable Sealant?

#1 Seller for Dowtherm and Hot Oils. Heat curing, Pliable putty-like consistency, Excellent travel, Gray color. Customer feedback reports applications up to 1250ºF (677ºC). Below 550ºF (288ºC), speed up the cure by adding 103-P Accelerator. Shelf-life is 6 months in closed containers. Refrigerated storage recommended.

Where is it used?

Flanges, Valves, Enclosures, Hot oils, Dowtherm, Gasoline, Hydrocarbons.

What temperature does it take, and what is it chosen against?

Service rating 250F to 950F (121C to 510C). That places it at the middle of the Deacon range, at a thinner consistency than 454. In practice it is chosen against 454, the denser putty in the same band, and 454-T, which is closest to this consistency.

Deacon publishes one service rating per product page and no comparison between them, so this is the part a buyer normally has to assemble by hand. Every figure above is transcribed from the manufacturer page linked on this listing.

Characteristics

• Begins to cure above 200ºF (93ºC)
• A positive seal can normally be reached before a full cure
