CSB XPL2200FR 12V 52Ah Sealed Lead-Acid Battery, Flame-Retardant Case

What is the CSB XPL2200FR?

The CSB XPL2200FR is a 12 V, 52 Ah valve-regulated lead-acid (VRLA) battery with absorbent glass mat (AGM) construction from the CSB XPL series (Extreme Power, Long Life). It is sealed and maintenance-free: it never needs water.

CSB designs this series for high-rate UPS and float service standby power. This part number has a flame-retardant (UL 94-V0) case as standard.

CSB lists this part as a non-stock item, so availability and minimum order quantity are confirmed with your quote.

What are the specifications of the CSB XPL2200FR?

Figures published by CSB in the XPL2200 datasheet (2026 edition), with the CSB price list attributes marked:

Nominal voltage: 12 V
Nominal capacity (CSB price list): 52 Ah
Watts per cell, 15 minutes to 1.67 V/cell, 25 °C: 201.5 W
Maximum charge current: 18.3 A
Maximum discharge current: 500 A
Internal resistance: approx. 5.6 mΩ
Terminal: I2 threaded insert for M6 bolt
Container: flame-retardant polypropylene (PP), UL 94-V0 (this part number)
Flame-retardant case: standard on this part number (CSB price list)
Weight, approx.: 36.7 lb (16.65 kg)
Dimensions (L x W x H): 228 x 138.4 x 206.3 mm (8.98 x 5.45 x 8.12 in)
Design life: Eurobat (20 °C) classification: >12 years, very long life
Discharge temperature range: -15 to 50 °C
Float charging voltage: 13.5 – 13.8 V per battery at 25 °C (77 °F)
Equalize / cycle charging voltage: 14.4 – 15.0 V per battery at 25 °C (77 °F)

How much power does the CSB XPL2200FR deliver in a 15-minute discharge?

CSB’s constant-current table gives 110 A for 15 minutes to 1.67 V/cell at 25 °C, and the constant-power table gives 1209 W per battery to the same end voltage. These are the figures to size a UPS or standby string against a 15-minute runtime.

How do I request a quote for the CSB XPL2200FR?

Request a quote by the part number XPL2200FR. Tell us the quantity you need and, where CSB lists more than one terminal or case option, which one. We confirm price, availability and lead time with the quote.
