CSB XHRL12475WFR 12V 119Ah Sealed Lead-Acid Battery, Flame-Retardant Case

What is the CSB XHRL12475WFR?

The CSB XHRL12475WFR is a 12 V, 119 Ah valve-regulated lead-acid (VRLA) battery with absorbent glass mat (AGM) construction from the CSB XHRL series (Extreme High Rate, Long Life). It is sealed and maintenance-free: it never needs water.

CSB designs this series for high-rate UPS and float service standby power. This part number has a flame-retardant (UL 94-V0) case as standard.

CSB lists this part as a non-stock item, so availability and minimum order quantity are confirmed with your quote.

What are the specifications of the CSB XHRL12475WFR?

Figures published by CSB in the XHRL12475W datasheet (2026 edition), with the CSB price list attributes marked:

Nominal voltage: 12 V
Nominal capacity (CSB price list): 119 Ah
Watts per cell, 15 minutes to 1.67 V/cell, 25 °C: 478.17 W
Maximum charge current: 47.5 A
Maximum discharge current: 800 A
Internal resistance: approx. 2.3 mΩ
Terminal: I2 threaded insert for M6 bolt
Container: flame-retardant polypropylene (PP), UL 94-V0 (this part number)
Flame-retardant case: standard on this part number (CSB price list)
Weight, approx.: 79.78 lb (36.2 kg)
Dimensions (L x W x H): 343 x 170 x 216.6 mm (13.5 x 6.69 x 8.53 in)
Case / group size (CSB price list): G31
Design life: up to 10 years in standby service at 25 °C; Eurobat (20 °C) classification: >12 years, very long life
Discharge temperature range: -15 to 50 °C
Float charging voltage: 13.5 – 13.8 V per battery at 25 °C (77 °F)
Equalize / cycle charging voltage: 14.4 – 15.0 V per battery at 25 °C (77 °F)
Standards (CSB datasheet): IEC 60896-21/22:2004, UL1973 Listed (MH66728) and UL1989 Recognized (MH14533)

How much power does the CSB XHRL12475WFR deliver in a 15-minute discharge?

CSB’s constant-current table gives 261 A for 15 minutes to 1.67 V/cell at 25 °C, and the constant-power table gives 2869 W per battery to the same end voltage. These are the figures to size a UPS or standby string against a 15-minute runtime.

How do I request a quote for the CSB XHRL12475WFR?

Request a quote by the part number XHRL12475WFR. Tell us the quantity you need and, where CSB lists more than one terminal or case option, which one. We confirm price, availability and lead time with the quote.
