CSB TPL12600TFR 12V 69Ah Sealed Lead-Acid Battery, Flame-Retardant Case

What is the CSB TPL12600TFR?

The CSB TPL12600TFR is a 12 V, 69 Ah valve-regulated lead-acid (VRLA) battery with absorbent glass mat (AGM) construction from the CSB TPL series (Telecom Front Access). It is sealed and maintenance-free: it never needs water.

CSB designs this series for float service standby power, such as telecom backup. This part number has a flame-retardant (UL 94-V0) case as standard.

What are the specifications of the CSB TPL12600TFR?

Figures published by CSB in the TPL12600T datasheet (2026 edition), with the CSB price list attributes marked:

Nominal voltage: 12 V
Nominal capacity (CSB price list): 69 Ah
Rated capacity, 20-hour rate to 1.75 V/cell, 25 °C: 69.6 Ah
Rated capacity, 8-hour rate to 1.75 V/cell, 25 °C: 63.7 Ah
Maximum charge current: 18 A
Maximum discharge current: 800 A
Internal resistance: approx. 6.27 mΩ
Terminal: I2 threaded insert for M6 bolt
Container: flame-retardant ABS, UL 94-V0
Flame-retardant case: standard on this part number (CSB price list)
Weight, approx.: 46.72 lb (21.2 kg)
Dimensions (L x W x H): 280 x 105 x 260 mm (11.02 x 4.13 x 10.23 in)
Case / group size (CSB price list): FT (Tall)
Design life: up to 12 years in standby service at 25 °C; Eurobat (20 °C) classification: >12 years, very long life
Discharge temperature range: -15 to 50 °C
Float charging voltage: 13.5 – 13.8 V per battery at 25 °C (77 °F)
Equalize / cycle charging voltage: 14.4 – 15.0 V per battery at 25 °C (77 °F)
Standards (CSB datasheet): IEC 60896-21/22:2004, UL1973 Listed (MH66728) and UL1989 Recognized (MH14533)

How do I request a quote for the CSB TPL12600TFR?

Request a quote by the part number TPL12600TFR. Tell us the quantity you need and, where CSB lists more than one terminal or case option, which one. We confirm price, availability and lead time with the quote.
