CSB EVH12150F2 12V 15Ah Sealed Lead-Acid Battery

What is the CSB EVH12150F2?

The CSB EVH12150F2 is a 12 V, 15 Ah valve-regulated lead-acid (VRLA) battery with absorbent glass mat (AGM) construction from the CSB EVH series (High Cycle, Extended Runtime). It is sealed and maintenance-free: it never needs water.

CSB designs this series for e-mobility and deep cycling.

What are the specifications of the CSB EVH12150F2?

Figures published by CSB in the EVH12150 datasheet (2026 edition), with the CSB price list attributes marked:

Nominal voltage: 12 V
Nominal capacity (CSB price list): 15 Ah
Rated capacity, 20-hour rate to 1.75 V/cell, 25 °C: 15.2 Ah
Rated capacity, 8-hour rate to 1.75 V/cell, 25 °C: 14.08 Ah
Maximum charge current: 4.5 A
Maximum discharge current: 180 A
Internal resistance: approx. 10.5 mΩ
Terminal: F2, Faston tab 0.250 in
Container: ABS, UL 94-HB
Weight, approx.: 10.14 lb (4.6 kg)
Dimensions (L x W x H): 151 x 98 x 101.8 mm (5.94 x 3.86 x 4.01 in)
Case / group size (CSB price list): M12
Design life: 1800 cycles at 100% depth of discharge, 25 °C
Discharge temperature range: -15 to 50 °C
Equalize / cycle charging voltage: 14.4 – 15.0 V per battery at 25 °C (77 °F)
Standards (CSB datasheet): IEC 60254-1:2005 & IEC 60254-2:2008 UL1989 Recognized (MH14533)

How do I request a quote for the CSB EVH12150F2?

Request a quote by the part number EVH12150F2. Tell us the quantity you need and, where CSB lists more than one terminal or case option, which one. We confirm price, availability and lead time with the quote.
