CSB-1001 Replacement Battery Pack, Replaces RBC4, 1 x GP12120F2 12V 12Ah

What is the CSB-1001?

The CSB-1001 is a CSB replacement battery pack that replaces RBC4. It contains 1 CSB GP12120F2 12 V 12 Ah sealed lead-acid battery with terminal cover, as listed on the CSB price list.

CSB packs each replacement pack individually in a ready-to-ship carton and manufactures packs to order.

What are the specifications of the CSB-1001?

Replaces: RBC4
Batteries in the pack: 1 x CSB GP12120F2
Battery voltage and capacity (CSB price list): 12 V, 12 Ah each
Included: terminal cover

What battery is inside the CSB-1001?

Figures for one CSB GP12120F2 battery, from the CSB GP12120 datasheet (2026 edition):

Weight per battery, approx.: 8.09 lb (3.67 kg)
Battery dimensions (L x W x H): 151 x 98 x 100.3 mm (5.94 x 3.86 x 3.95 in)
Battery terminal: F2, Faston tab 0.250 in
Battery design life: up to 5 years in standby service at 25 °C; Eurobat (20 °C) classification: 3-5 years, standard commercial

How do I request a quote for the CSB-1001?

Request a quote by the part number CSB-1001. Tell us the quantity you need and we confirm price, availability and lead time with the quote.
