Hydrotex BIO-XPL™ FRHF

Price range: $2,335.48 through $11,093.58

Grade

Pack size

Clear

SKU: N/A

Manufacturer:

Hydrotex

Bulk Orders

Competitive Pricing

Short Lead Times

Consolidated Shipping

Prompt Response

Request a Quote

What is Hydrotex BIO-XPL™ FRHF?

BIO-XPL™ FRHF is a hydraulic fluid designed to replace mineral oil-based anti-wear hydraulic fluids in applications with fire hazards or environmental concern. Formulated with renewable biosynthetic esters and non-toxic additives, BIO-XPL FRHF provides maximum wear protection for extended asset life and the ultra-high viscosity index delivers improved hydraulic efficiency and productivity. The readily biodegradable fluid has low aquatic toxicity and will not bioaccumulate, minimizing the environmental damage and cleanup expense for an accidental release.

Why choose Hydrotex BIO-XPL™ FRHF?

Lowers fire risks and impacts
Excellent wear resistance
Ultra-high viscosity index for efficiency over a wide temperature range
Superior air release & demulsibility
Compatible with traditional mineral oil hydraulic fluids & elastomers ™ BIO-XPL FRHF is FM Approved per Standard 6930 for enhanced safety in applications with potential fire hazards.
Oil Lubricated Hydraulic Systems
Metal Production Facilities
Paper & Corrugated Equipment

Which specifications does Hydrotex BIO-XPL™ FRHF meet?

ASTM D8029
DIN 51502 HFDU
EPA Vessel General Permit
FM Approval Standard 6930
ISO 12922 HFDU
ISO 15380 HEES
ISO 6743-4 HFDU
ISO Grade

Hydrotex BIO-XPL™ FRHF technical specifications

Property	Test method	ISO 46	ISO 68
ISO Grade	ASTM D2422	46	68
Kinematic Viscosity, cSt @ 40°C	ASTM D445	46.5	67.4
Kinematic Viscosity, cSt @ 100°C	ASTM D445	9.4	12.3
Viscosity Index	ASTM D2270	190	184
Flash Point, °F (°C)	ASTM D92	> 572 (300)	> 572 (300)
Pour Point, °F (°C)	ASTM D97	-49 (-45)	Confirmation pending
Density, g/ml @ 15.5°C	ASTM D1298	0.919	0.929
Density, lb/gal @ 60°F	ASTM D1298	7.67	7.755
4-Ball Wear, scar diameter, mm	ASTM D2266	0.495	0.51
FZG Scuffing, A/8.3/90, Fail Stage	ASTM D5182	12+	12+
Copper Corrosion, 3 hr @ 121°C	ASTM D130	1A	1A
Rust Test, Distilled Water	ASTM D665A	Pass	Pass
Rust Test, Syn. Sea Water	ASTM D665B	Pass	Pass
Air Release, min @ 50°C	ASTM D3427	2.5	6
Appearance, @ 25°C	—	Clear & Bright	Clear & Bright
Biodegradability, %	OECD 301B	> 70	> 80
Dynamic Viscosity, cP @ -10°C	ASTM D7042	550	950
Dynamic Viscosity, cP @ -20°C	ASTM D7042	1300	2400
Dynamic Viscosity, cP @ -30°C	ASTM D7042	3750	—
Dynamic Viscosity, cP @ 0°C	ASTM D7042	300	500
Fire Point, °F (°C)	ASTM D92	> 680 (360)	> 680 (360)
Foam, Blow/Settle ml/ml, Seq. I, II, III	ASTM D892	pass	pass
KRL Shear Stability, % visc. loss 20hr	CEC L-45-A-99	< 1	< 1
Kinematic Viscosity, cSt @ 0°C	ASTM D445	340	610
Renewable Content, %	ASTM D6866	> 88	> 90
TOST Oxidation Stability, hrs	ASTM D943	2000+	2000+
V104C Pump Wear, wt. loss vanes, mg	ASTM D7043	< 5	< 5
Water Separability, min @ 54°C	ASTM D1401	15	15

Which pack sizes are available?

Part number	Grade	Pack size	Unit
2650-046-1	ISO 46	1900 LB	Tote
2650-046-2	ISO 46	400 LB	Drum
2650-068-1	ISO 68	1900 LB	Tote
2650-068-2	ISO 68	400 LB	Drum

Is Hydrotex BIO-XPL™ FRHF hazardous to handle?

Not classified as hazardous under GHS criteria. Land transport (DOT): Not Regulated for Land Transport. Consult the safety data sheet before use.

How do I order Hydrotex BIO-XPL™ FRHF?

The list price for each pack is shown on this page and every pack is ordered by quote. Ordered by quote: 400 LB and 1900 LB – shipping for these packs is quoted per order, so send us the part number from the pack table above and we will confirm the delivered price. A grade or pack that is not listed is quoted the same way.

2650-046 SDS
2650-068 SDS
TDS
