3M DBI-SALA Lad-Saf Grab Bar Extension Top Bracket
Bulk Orders
Details
Highlights
- Top Bracket Grab Bar Extension for 3M™ DBI-SALA® Lad-Saf™
- Durable Steel construction
- Various options of brackets for different bracket styles and sizes
The Lad Saf™ flexible cable system consists of a top and bottom bracket that act as anchors for a steel cable that runs the length of the climbing area. A Lad Saf™ sleeve connects the worker to the system, automatically follows the user during the climb and locks onto the cable in the event of a fall, allowing the user to regain their footing. Designed for ease of use, economy and versatility, optional brackets/designs are available for bolting or welding the system, choose rung clamp sizes/styles, choose systems for straight or curved ladders and for connection to wood, concrete or steel structures. Many different brackets, styles and configurations are available to suit almost any application. In addition, the versatile system can be used by up to four workers simultaneously for added jobsite flexibility.
Typical properties
Attachment Type | Bolt-On, Four Rungs, None |
Case Quantity | 1 |
Connected Safety ID Equipped | No, Yes |
Dimensions | 1.5 in x 5.5 in x 66.5 in,3 in x 2 in x 49.5 in |
For Use With | Fixed Ladders |
Install Type | Permanent |
Maximum Number of Users | 1-4 Users, One |
Net Weight (Imperial) | 18 lb, 21 lb |
Net Weight (Metric) | 8.2 kg, 9.5 kg |
Product Series | Lad-Saf™ |
Product Type | Grab Bar Extension Top Bracket for Fixed Ladder |
Recommended Industry | General Industrial, Oil & Gas, Transportation, Utilities, Wind Energy |
Specifications Met | ANSI A14.3-1992, FAA RR-S-001301, OSHA 1910.27 |
Structure Type | Straight Ladder. |
Weight (Imperial) | 18 lb., 21 lb. |
Weight (Metric) | 8.2 kg, 9.5 kg |
Weight Capacity | 310 lbs. (141 kg) |
